Analyzers

The CytoFLEX LX flow cytometer is an expansion of the CytoFLEX platform: a unique instrument based on photodiode technology, equipped with 5 lasers, capable of detecting up to 19 fluorescences and 2 scattering parameters simultaneously.

Digital signal processing on 7 decades of dynamic range.

Excellent resolution of nanoparticles thanks to the new VSSC parameter.

• Resolution:

  • < 300 nm particles (488 nm side scatter)
  • < 80 nm polystyrene particles (405 nm side scatter)
  • rCV 3%
• collections vessels:

  • 5 ml, 2 ml, 1.5 ml;
  • 96w plates;
• absolute counting.

5 activated lasers / 19 color parameters:

Technical features (brochure):

• 3 laser (8 fluorescence)

  • 405 nm, 2 PMT
  • 488 nm, 4 PMT
  • 633 nm, 2 PMT
• Sample acquisition possible also from multiwell plates.

Technical features (brochure):

• 2 laser (6 fluorescence)

  • 488 nm, 4 PMT
  • 633 nm, 2 PMT

Technical features (brochure, specifications):

• 3 laser (10 fluorescence)

  • 405 nm, 2 PMT
  • 488 nm, 5 PMT
  • 633 nm, 3 PMT

Rules for users accredited to the Gallios flow cytometer
